Process Flow
product transplanting → labeling → inspection and rejection (optional) → finished product → next
Process Characteristics Description:
Power-driven synchronous tension control for label supply, stable and fast, ensuring the speed of label delivery and the precision of labeling.
This equipment can label cardboard boxes, packaging bags, and flat surfaces, etc.; it has a wide range of applications and strong adaptability.
Compact body, suitable for various production line connections.
Guard correction positioning, ensuring the stability and accuracy of correction.
Label synchronous positioning mechanism, label positioning error is less than ±0.5mm.
Touch control human-machine operation interface, any abnormalities are displayed and guided for troubleshooting, simple operation, anyone can easily operate and quickly use this equipment.
Multiple emergency stop buttons can be added at appropriate positions on the production line to make the operation safe and production smooth.
Label stripping distance is automatically calculated by length and photoelectricity with microcomputer, no need to adjust the photoelectric position, any label length can be modified on the human-machine interface, convenient to use.
Multiple memory group functions, no need to re-adjust the parameters when replacing, operation is more convenient.
The labeling head can be universally adjusted and is suitable for various specifications of bottles.
The case is made of stainless steel SUS304 material and T6 aluminum alloy, which will never rust.
Plant Parameter
机器尺寸： | 见尺寸参考图 |
电压规格： | AC220V 50/60HZ 单相 |
系统功率： | 2KW |
贴标速度： | 60-100个/分钟（视标签及样品尺寸而定） |
贴标精度： | 小于±1mm（产品变形误差除外） |
空气压力： | 5-7kg/cm2（有剔除或气动打印时需要） |
贴标合格率： | ≥ 99.9% |
最大标签供应： | 直径350mm,纸卷内径76mm（可定制） |
出标精度： | 0.2mm |
进出料方向： | 左进→右出/右进→左出 |
适用容器范围: | 长度15-100mm,宽度10-100mm,高度40-350mm（可定制） |
适用标签范围: | 高度15-100mm,长度10-200mm（可定制） |
标头高度： | 定制（特殊尺寸亦可接受非标制作） |
